LGS318 18-PORT | SWITCHES | Linksys

LINKSYS LGS108P 8-PORT BUSINESS DESKTOP GIGABIT POE+ SWITCH Upgrade the data paths of your local wired network to information superhighways with 8-port desktop Gigabit PoE switches. Learn More Wired connection speed up to 1,000 Mbps 8 Gigabit Ethernet autosensing ports Power over Ethernet (PoE) support Easy plug & play connection QoS Meets EEE (Energy Efficient Ethernet) 802.3az standard
Manufacturer: Linksys
Call for pricing
    • Model Name:
      LGS318
    • Network Standards:
      • IEEE 802.3
      • IEEE 802.3u
      • IEEE 802.3ab
      • IEEE 802.3z
      • IEEE 802.3x
      • IEEE 802.3ad
      • IEEE 802.3az
      • IEEE 802.1d
      • IEEE 802.1Q/p
      • IEEE 802.1X
    • Memory:
      128 MB
    • LEDs:
      System (blue), Link/Act (green)
    • System Power Consumption without PoE+:
      • 110V:13.55W
      • 220V:13.66W
    • Forwarding Rate:
      26.79 Mpps
    • Switching Capacity:
      36 Gbps
    • Jumbo Frame (FE, GE):
      9K
    • Dimensions (LxWxH):
      440 x 200 x 44 mm (17.3 x 7.9 x 1.7 in.)
    • Weight:
      2.378 kg (5.23 Ibs.)
    • Power Input:
      • 100–240V
      • 50-60 Hz
      • (0.7A max)
    • Operating Temperature:
      0 to 50°C (32 to 122°F)
    • Storage Temperature:
      -40 to 70°C (-40 to 158°F)
    • Operating Humidity:
      10 to 90% RH
    • Storage Humidity:
      10 to 90% RH (non-condensing)
    • Spanning Tree:
      IEEE 802.1d Spanning Tree, IEEE 802.1s Multiple Spanning Tree, IEEE 802.1w Rapid Spanning Tree
    • Link Aggregation:
      IEEE 802.3ad LACP, up to 4 groups with up to 8 ports per group
    • VLAN:
      Port-based and 802.1q tag-based VLANs, Management VLAN, Guest VLAN support, Dynamic VLAN assignment via Radius server with 802.1x client authentication
    • Auto Voice VLAN:
      Voice traffic is automatically assigned by OUI to a voice-specific VLAN and treated with appropriate levels
    • IGMP Snooping:
      IGMP (v1/v2/v3) snooping provides for fast client joins and leaves of multicast streams and limits bandwidth-intensive video traffic to only the requestors; supports 256 multicast groups
    • HOL Blocking Prevention:
      Head-of-line (HOL) blocking prevention
    • Port Mirroring:
      Traffic on multiple ports (up to four ports) can be mirrored to another port for analysis with a network analyzer
    • Security Features:
      • 802.1x Radius authentication
      • DHCP snooping
      • IP-MAC binding
      • Port security supports limited dynamic lock and locked MAC address
      • Management access control
    • Storm Control:
      Broadcast, flooding, and multicast
    • RMON:
      Embedded remote monitoring (RMON) software agent support for enhanced traffic management, monitoring, and analysis
    • Management Interface:
      • HTTP
      • HTTPS
    • Other Management:
      Telnet (menu CLI), DHCP client, system log, configuration unload and backup via HTTP or TFTP, PING, dual images, SNTP
    • SNMP:
      • Version 1
      • Version 2c
    • Firmware Upgrade:
      • Web Browser (HTTP/HTTPS)
      • TFTP
    • QoS - Class of Service:
      Port-based, 802.1p priority-based, IPv4/v6 IP DSCP-based
    • Combo Ports (RJ45 + SFP):
      2 combo on ports g17, g18
    • Copper FE/GE Ports (RJ45):
      g01–g08, g09–g16
    • Green Power Mode:
      EEE+, Short Reach + Energy Detect
    • QoS - Priority Levels:
      4 hardware queues
    • QoS - Scheduling:
      Priority queuing and weighted round robin (WRR)
    • Total System Ports:
      18GE
    • Mac Addresses:
      8K
