| Applicable Fibers | SM(G.652&G.657)?MM(G.651)?DS(G.657)?NZDS(G.655) | | Splice Loss | 0.025dB(SM)?0.01dB(MM)0.04dB(DS/NZDS) | | Focus mode | Auto focus | | Fiber alignment | Core/cladding alignment Manual alignment | | Typical splicing time | 5S(AI-9) / 6S(AI-8C) /6S(AI-7V) / 8S(AI-7C) | | Typical heating time | 15S (AI-9) / 15 S (AI-8C) /15 S (AI-7V) / 18 S (AI-7C)
Fast heating function, heating time can be set | | Control technology | Real-time control and calibration of fusion ARC | | Return loss | Better than 60DB | | Fiber diameter | Cladding Diameter 80-150µm,Coating Diameter 100-1000µm | | Fiber Cleave Length | Coating less than 250µm:8-16mmCoating less m250-1000µm:16mm | | Heat shrinkable tube | 60mm?40mm | | Visual Fault Locator(AI-9) | Power:15mw,2hzflashing And Constantly Bright Mode |
| | Tension Test | Standard 2N | | Fiber holders | Multi function holders,Applicable for SM, MM, bare fiber, pigtail, rubber-insulated, multi fiber cable | | Magnification | 300 for X or Y view, 150 for X or Y view | | Screen | 5.1 inch TFT color display | | Software upgrade | Mobile APP update,Turn on Bluetooth sync to the machine | | Splicing Mode | Normal / high precision splicing | | Splicing record storage | Synchronize to the phone, the server to cloud storage unlimited | | Built-in battery | 7800 mA high-capacity lithium battery, charging time = 3.5 hours, continuous splicing and heating about 240 times | | Power supply | Input AC100-240V 50 / 60HZ, output DC13.5V / 4.8A, the current power mode can be identified, real-time detection of battery power | | Operating Conditions | Temperature -15 ~ +50 ?, humidity: <95% RH (no condensation),Working altitude: 0 ~ 5000m. Resist max. wind speed: = 15m / s | | lighting | External | | Optical Power Meter(AI-9) | Wavelength:850nm?1300nm?1310nm?1490nm?1550nm?1625nm
Measuring Range:-70 ~ +6db Absolute Error:<0.3db(-50dbm ~ +3dbm Range) |
|
