N150RB | Router | Totolink

Complies with IEEE 802.11n and IEEE 802.11g/b standards for 2.4GHz Wireless LAN.Up to 150Mbps wireless data rate.
Call for pricing

N150RB is a WLAN Router with 1 high gain antenna. It allows users to access Internet by DHCP/PPPoE/Static IP and can deliver up to 150Mbps wireless data rate. With Wireless Multibridge and WDS function, it can significantly extend the wireless coverage and allow more terminals to access Internet with stable wireless signal. For security, it provides most advanced WEP, WPA, WPA2 and WPA/WPA2 (TKIP+AES) encryption to prevent outside intrusion and protect your personal information from being exposed. Generally, it is a high performance and cost-effective solution for home and small offices.


Excellent Wireless Network Performance
Complying with the 802.11n standard, it delivers up to 150Mbps speed for further transmission distance and most reliable connection for users to enjoy the best wireless connection in your entire home. Besides, broadband Internet connection sharing over a secure wireless network with numerous computers can be realized easily.



Effective Multi-SSID function
Multi-SSID function is designed for users who want to set up extra wireless networks for guests or friends with better access control. Different SSIDs and passwords help to protect your internal network security from guests. Up to 3 SSIDs is supported without conflict with each network. Generally, it is easy maintenance for manager in those companies which consist of many different departments.



Virtual Private Network(VPN)
Up to 5 VPN tunnels are provided for remote access based on PPTP protocol. It can not only protect the privacy of your information, but also simplify network management. For some small enterprises, if staff on business needs to access company?? intranet remotely, they can easily use the VPN server function to get information through Internet remotely.



Outstanding Bandwidth Control with Smart QoS
QoS function can be used to control the data rate of every PC to make sure the bandwidth is used reasonably. However, the more users in LAN, the more difficult to set speed limitation and bandwidth for everyone. Smart QoS makes it possible to easily assign bandwidth equally no matter how much the users are. Just enable the smart QoS function without other complex configuration, bandwidth of every PC can be control effectively.



WDS for optimal coverage
Features with WDS function, the device allows two or more wireless AP/Router connecting with each other to farther distance. It is very practical for users whose house has many rooms and even living in two different buildings (300m max.) in one residential area without obstacles between them.



Robust Security
The most advanced WPA/WPA2 (TKIP/AES) encryption is provided to ensure the security of wireless connection. Only the users who known the SSID and encryption key can connect to the network, so that users needn?? worry about being occupied by others. What?? more, to keep the Internet browsing experience safe, it provides IP/MAC/URL filter to strengthen the security outside and inside the network.

Firmware - N150RB-V1

ModelDownloadVersionUpdated
N150RB-V1TOTOLINK N150RB-V1_en_9_76.zipen_9_762015-08-08
N150RB-V1TOTOLINK N150RB-V1_en_9_74.zipen_9_742015-07-25

Quick Install Guide

ModelDownloadVersionUpdated
N150RBN150RB QIG V1.0.pdfver1.02014-07-10


ModelDownloadVersionUpdated
N150RBN150RB_Photo002.jpgResolution1200x12002014-08-22
N150RBN150RB_Photo001.jpgResolution1200x12002014-08-22
