EBC-1124 Embedded Computer

Intel® Celeron® J1900, Onboard 4G RAM, 2 LAN/4 COM/4 USB/DVI/Line-out/9~24Vdc
Manufacturer: Darveen
Call for pricing
Features
~Intel® Celeron® Processor J1900 (2.0 GHz)
~ 4 x COM Ports (1 x RS-232/485)
~ 2 x GbE, 4 x USB , 1 x DVI
~ 1 x 2.5" SATA HDD / SSD, 1 x mSATA
~ 2 x Mini PCIe
~ 9~24V DC Power Input

Parameters

System
ProcessorIntel® Celeron® Processor J1900 Quad-Core 2.0 GHz
Memory4G DDR3 Onboard
GraphicIntel® Gen7 Intel Graphics with DX11*, OGL3.2
Operating SystemWindows 7/8, WS7E, WS8
Storage
Type1 x 2.5" SATA HDD / SSD, 1 x mSATA
RF Communication
3G/4GGSM/LTE (Optional)
WLAN802.11a/b/g/n/ac  (Optional)
BluetoothBluetooth 4.0  (Optional)
GPSGPS/Beidou  (Optional)
I/O Connectors
COM3 x RS-232
1 x RS-232/485
USB3 x USB 2.0
1 x USB3.0
LAN2 x Intel i211 for GbE
Video1 x DVI-I
Expansion1 x full-size mini PCIe, 1 x half-size mini PCIe
Qualification
CertificationsCE, FCC Class A
Environmental
Operating Temp.-20 ~ 60?(SSD)
Storage Temp.-40 ~ 85?
Relative Humidity10 ~ 95%
Power Management
Power InputDC 9-24 V
Mechanical
HousingAluminum alloy
MountingWall-mount
Dimension (W x H x D)154 x 112.5 x 55 mm
Weight0.9kg
Optional Modules
GPIO4 x GPI and 4 x GPO
Power IgnitionACC
External LVDSDual channel 24-bit, max resolution 1920x1200@60
Remote Power On/Off2-pin Remote Power On/Off Switch
CAN2 x CANbus 2.0B
External Cfast1 x CFast2.0 Slot
Video Capture4 CCTV Cameras input and 4 MIC (120/100fps)
LAN1/2 x RJ45 GbE LAN(Intel i210)
