BR1000G-JP | APC

APC RS 1000VA Power-Saving Battery Backup, 100V
Manufacturer: APC
Call for pricing
Model NameAPC RS 1000VA Power-Saving Battery Backup, 100V
IncludesTelephone Cable,USB cable,User Manual,Warranty card
Standard Lead TimeUsually in Stock
Product DistributionJapan
Output Power Capacity600 Watts / 1000 VA
Max Configurable Power (Watts)600 Watts / 1000 VA
Nominal Output Voltage100V
Output Frequency (sync to mains)50/60 Hz +/- 3 Hz user adjustable +/- 0.1
nullLine Interactive
Waveform Type--
Output Connections(4) NEMA 5-15R (Battery Backup),(4) NEMA 5-15R (Surge Protection)
BypassBuilt-in Bypass
Nominal Input Voltage100V
Input Frequency50/60 Hz +/- 3 Hz (auto sensing)
Input ConnectionsJapanese 2-pin,NEMA 5-15P
Cord Length1.83 meters
Input voltage range for main operations83 - 122
Maximum Input Current12
Input Breaker Capacity15
Batteries & Runtime
Battery TypeMaintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time8
Replacement BatteryAPCRBC123J
Communications & Management
Interface Port(s)Optional Simple Signalling RS232 cable,USB
Control panelMulti-function LCD status and control console
Audible AlarmAlarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering
Surge energy rating355
Data Line ProtectionAnalog phone line for phone/fax/modem/DSL (RJ-45 connector),Network line - 10/100 Base-T Ethernet (RJ-45 connector),Coaxial cable for CATV/SATV/modem/Audio-Video (coax connector)
Maximum Height250 mm
Maximum Width100 mm
Maximum Depth382 mm
Net Weight11.36 kg
Shipping Weight12.34 kg
Shipping Height337 mm
Shipping Width225 mm
Shipping Depth487 mm
Master Carton Units1.0
Units per Pallet30.0
Pallet Dimensions1169 mm
Pallet Weight393.28 kg
Operating Environment0 - 40 °C
Operating Relative Humidity0 - 95
Operating Elevation0-2952.6 meters
Storage Relative Humidity0 - 95
Storage Elevation0-14763.6 meters
Audible noise at 1 meter from surface of unit45.000
Online Thermal Dissipation67.600
Regulatory ApprovalsTUV,UL Listed,VCCI Class B
Standard Warranty2 years (Japan only)
Equipment protection policy--
Sustainable Offer Status
