APC - BE325-GR

APC Back-UPS,185 Watts /325 VA,Input 230V /Output 230V
Manufacturer: APC
Call for pricing

Output

Output Power Capacity
185 Watts / 325 VA
Max Configurable Power
185 Watts / 325 VA
Nominal Output Voltage
230V
Output Frequency (sync to mains)
47 - 63 Hz
Topology
Standby
Waveform Type
Stepped approximation to a sinewave
Output Connections
(2) Schuko CEE 7 (Battery Backup)Schuko CEE 7
(2) Schuko CEE 7 (Surge Protection)Schuko CEE 7

Input

Nominal Input Voltage
230V
Input Frequency
50 Hz +/- 3 Hz
Input Connections
Schuko CEE 7/7PSchuko CEE 7/7P
Cord Length
1.83 meters
Input voltage range for main operations
180 - 266V
Maximum Input Current
4A
Input Breaker Capacity
4  A

Batteries & Runtime

Battery Type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time
24 hour(s)
Replacement Battery
RBC™ Quantity
1
Runtime

Energy Use/Efficiency

LoadEfficiency
25%85.9%
50%92.1%
75%94.2%
100%95.2%

Communications & Management

Control panel
LED Status display with On Line : On Battery
Audible Alarm
Alarm when on battery : distinctive low battery alarm

Surge Protection and Filtering

Surge energy rating
310 Joules
Filtering
--
Data Line Protection
RJ-11 Modem/Fax/DSL protection (two wire single line)

Physical

Maximum Height
115.00 mm
Maximum Width
360.00 mm
Maximum Depth
95.00 mm
Net Weight
4.00 KG
Shipping Weight
4.60 KG
Shipping Height
153.00 mm
Shipping Width
465.00 mm
Shipping Depth
116.00 mm
Master Carton Units
1.00
Master Carton Dimensions (Length x Width x Height)
9.65 inches
Master Carton Weight
41.36 lbs.
Color
Charcoal
SCC Codes
1073130421114 0
Units per Pallet
64.00

Environmental

Operating Environment
0 - 40 °C
Operating Relative Humidity
5 - 95%
Operating Elevation
0-3000 meters
Storage Temperature
-15 - 45 °C
Storage Relative Humidity
5 - 95%
Storage Elevation
0-15000 meters
Audible noise at 1 meter from surface of unit
45.00 dBA
Online Thermal Dissipation
31.00 BTU/hr

Conformance

Regulatory Approvals
CE, EN 50091-1, EN 50091-2, GS Mark, NEMKO
Standard Warranty
2 years repair or replace

Sustainable Offer Status

RoHS
Compliant
PEP
Available in Documentation tab
EOLI
Available in Documentation tab
User Manual
Type
Size

PDF
236KB


SurgeArrest + Battery Backup BE325-GR
Agency Approval
Type
Size

PDF
46KB


RoHS Certification of Compliance - UPSs
PDF
490KB


EN 50091-2:1995; EN 55022:1998; IEC 61000-3-2:2000; IEC 61000-3-3:1995; IEC 1000-2-2;1990; IEC 801-2:1991; IEC 801-3:1984; IEC 801-4:1988
Environmental Profile
Type
Size

PDF
463KB


Product Environmental Profile 1 for the Back-UPS Product Range
PDF
407KB


End of Life Instruction (EoLI) for the Back-UPS Product Range
Brochure
Type
Size

PDF
59KB


Two page brochure with top level features, benefits and specs.
